| Brand Name : | Mobydata |
| Model Number : | KS200 |
| Price : | 100USD |
| Supply Ability : | 3000PCS/mouth |
| Structure Parameter | |
| Overall dimensions (L X W X H) 67mmx87mmx183mm | |
| Weight "177g | |
| Electrical Parameters | |
| ESD ± 15 KV air, ± 8 KV contact | |
| Input Voltage " 5V | |
| Input and output interfaces USB, RS232; key trigger, infrared trigger | |
| Environmental parameters | |
| Drop Can withstand 18 times 2 meters steel plate drop, 40,000 times 5 cm light drop | |
| Roller 2000 times 0.5 meter steel plate flip | |
| Temperature "Operating temperature: -20 to 50 °C | |
| Storage temperature: -40 to 70 °C | |
| Humidity "0 to 95% relative humidity, non-condensing | |
| Ambient light "Ambient light: -40 to 70 °C | |
| Dust and waterproof rating | |
| IP65 | |
| Performance Parameters | |
| Sensor resolution | |
| 1280x800 | |
| Illumination Red and white illumination | |
| Aiming " "laser | |
| Field of view "42°H x 26.8°V | |
| Barcode Contrast Ratio | |
| Minimum 15% print contrast | |
| Scanning Angle "Tilt Angle Pitch: +/- 60°; Roll Angle Roll: +/-180°; Deflection Angle Yaw: +/- 60° | |
| Barcode Resolution | |
| Minimum 3 mil | |
| Read Indicator Buzzer; LED Indicator; Vibration Indicator | |
| Decoding Capability | |
| 2D Code Aztec Code; China Han Xin Code; Data Matrix; MaxiCode | |
| Micro QR Code; QR Code; Digimarc; Dot Code; OCR | |
| 1D Code "All standard 1D codes including GS1 DataBar™. | |
| Postal Codes Australian Post; British Post; China Post; IMB; Japanese Post | |
| KIX Post; Korea Post; Planet Code; Postnet; Royal Mail Code | |
| Stacked Codes EAN/JAN Composites; GS1 DataBar Composites | |
| GS1 DataBar Expanded Stacked; GS1 DataBar Stacked | |
| GS1 DataBar Stacked Omnidirectional; MacroPDF | |
| MicroPDF417; PDF417; UPC A/E Composites | |
| Reading Range | |
| 3 mil Code 39 | |
| 13 mil UPC | |
| 10 mil DM | |
| 20 mil QR" "10 mm - 90 mm | |
| 10 mm - 200 mm | |
| 0 mm - 100 mm | |
| 60 mm - 250 mm" | |
|
|
